Machine park
Modern technologies in the service of quality
KIMLA LF1530 PowerCut - Fiber Laser 6 kW
Technical specification
- Manufacturer: KIMLA (Poland)
- Working area: 1500 × 3000 mm
- Laser source: Fiber 6 kW
- Wavelength: 1070 nm
- Drives: Linear Drive
- Max speed: 200 m/min
- Acceleration: up to 3G
- Accuracy: ± 0.05 mm
Cutting capabilities
- Carbon steel: up to 25 mm
- Stainless steel: up to 20 mm
- Aluminium: up to 15 mm
- Copper/brass: up to 10 mm
Equipment
- ✓ Automatic sheet storage
- ✓ Automatic pallet changer
- ✓ Auto-focus system
- ✓ Cutting process monitoring
- ✓ CAD/CAM software
BLM LT9 Combo - 3D/2D Laser
Technical specification
- Manufacturer: BLM GROUP (Italy)
- Model: LT9 Combo (3D/2D)
- Laser source: Fiber 3 kW
- Profile length: up to 6000 mm
- Profile size: 20–250 mm
- Sheets: 1500 × 3000 mm
- Accuracy: ± 0.1 mm
- Cutting angle: any (5 axes)
Technological capabilities
- Profiles: round, square, rectangular, channels
- 3D cutting: holes, cutouts, angle undercuts
- 2D cutting: sheet plates up to 25 mm
- Materials: steel, stainless, aluminium, copper
Equipment
- ✓ Automatic profile loading system
- ✓ 5-axis cutting head
- ✓ Interchangeable pallet table (2D)
- ✓ Artube & Artcut software
- ✓ Real-time collision detection
- ✓ Automatic calibration
EHT ProfiPress 230 - CNC Press Brake
Technical specification
- Manufacturer: EHT (Germany)
- Model: ProfiPress 230
- Sheet thickness: 1–10 mm
- Bending length: 4050 mm
- Press force: 2300 kN (230 tons)
- Working length: 3550 mm
- Max table-beam gap: 500 mm
- Throat depth: 305 mm
- Ram crowning: ± 10 mm
Technological capabilities
- Control: CNC with bending angle control
- Bending precision: ± 0.5°
- Materials: mild steel, stainless steel, aluminium
- Applications: enclosures, panels, structures, profiles
Equipment
- ✓ CNC control
- ✓ Laser angle measurement system
- ✓ Beam deflection compensation
- ✓ Extensive tool library
- ✓ Offline programming
- ✓ Laser safety guards
AMADA HFE-M2 50-20 - Press Brake
Technical specification
- Manufacturer: AMADA (Japan)
- Model: HFE-M2 50-20
- Sheet thickness: 0.5–5 mm
- Press force: 500 kN (50 tons)
- Beam length: 2090 mm
- Clearance between uprights: 1665 mm
- Table width: 60 mm
- Bending precision: ± 0.3°
Technological capabilities
- Control: AMADA CNC with angle control
- Materials: mild steel, stainless steel, aluminium
- Applications: precision parts, panels, enclosures
- Maximum precision: ideal for thin sheets
Equipment
- ✓ AMADA CNC control
- ✓ Laser angle measurement system
- ✓ Automatic deflection correction
- ✓ Precision tool set
- ✓ 2D/3D programming
- ✓ CNC-controlled back-gauge
AMADA HFT 130-3 - Press Brake
Technical specification
- Manufacturer: AMADA (Japan)
- Model: HFT 130-3
- Sheet thickness: 0.5–12 mm
- Press force: 1300 kN (130 tons)
- Working length: 3150 mm
- Bending precision: ± 0.3°
Technological capabilities
- Control: AMADA CNC NC9-EX
- Materials: mild steel, stainless steel, aluminium
- Applications: panels, enclosures, medium-size structures
Equipment
- ✓ AMADA CNC NC9-EX control
- ✓ Laser angle measurement system
- ✓ Automatic deflection compensation
- ✓ CNC-controlled back-gauge
- ✓ Multi-angle tool set
- ✓ Offline programming
OTC Robotic Welding Station
Manipulator All-B4L
- Number of axes: 6
- Maximum payload: 4 kg
- Maximum working range: 2,008 mm
- Position repeatability: ± 0.08 mm
Welding Machine DP400
- Output: 400 A
- Phases: 3
- Output voltage: 12–38 V
- Output current: 30–400 A
- Duty cycle (10 min/40°C): Pulse = 50% / DC = 60%
- Supply voltage: 400 V ± 15%
Positioner TC-700-T
- Maximum payload: 400 kg per side
- Working area: 2000 × 900 mm
- Number of working areas: 2
- Position repeatability: ± 0.2 mm
Technological capabilities
- ✓ Robotic MIG/MAG welding
- ✓ High repeatability and precision
- ✓ Dual-station positioner
- ✓ Offline programming
- ✓ Welding parts up to 400 kg
- ✓ Automation of welding processes
Powder Coating Line - Complete Coating System
Curing Oven PSG-1
- Function: melting and curing coatings up to 220°C
- Drying parts: after chemical treatment up to 150°C
- Maximum load: 1500 kg
- Max load dimensions: 3400 × 1000 × 1800 mm
- Chamber dimensions: 3600 × 1200 × 2000 mm
Spray Washer
- Function: surface preparation for coating
- Process: spray degreasing and phosphating
- Operating temperature: up to 55°C
- Maximum load: 1500 kg
- Max load dimensions: 3400 × 1000 × 1800 mm
Technological capabilities
- ✓ Complete powder coating line
- ✓ Iron phosphating by spray method
- ✓ Conversion coating for excellent adhesion
- ✓ Pickling of galvanized parts
- ✓ Curing coatings up to 220°C
- ✓ Large part dimensions (up to 3.4 m)
